Description
Capacity | 256GB |
Form factor | M.2 2280 |
NAND Flash | 3D NAND |
Controller | RTS5766DL |
Dimensions (L x W x H) | 80 x 22 x 3.13mm / 3.15 x 0.87 x 0.13inch (with heat sink) 80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink) |
Weight | 9g / 0.32oz (with heat sink) 6.2g / 0.22oz (without heat sink) |
Interface | PCIe Gen3 x4 |
Sequential Read (Max) | Up to 2,400MB/s* |
Sequential Write (Max) | Up to 1,800MB/s* |
4KB Random Read IOPS(Max) | Up to 200K* |
4KB Random Write IOPS(Max) | Up to 150K* |
Operating temperature | 0°C – 70°C |
Storage temperature | -40°C – 85°C |
Shock resistance | 1500G/0.5ms |
MTBF | 1,500,000 hours |
Terabytes Written (TBW) | 520TB** |
Warranty | 3-year limited warranty |
