Description
| Antenna | External detachable antenna x 3 Internal antenna x 2 |
| Button | WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button |
| Coverage | Very large homes |
| Data Rate | 802.11a : 6,9,12,18,24,36,48,54 Mbps 802.11b : 1, 2, 5.5, 11 Mbps 802.11g : 6,9,12,18,24,36,48,54 Mbps 802.11n : up to 450 Mbps 802.11ac : up to 1734 Mbps 1024QAM (2.4GHz) : up to 750 Mbps 1024QAM (5GHz) : up to2167 Mbps |
| Dimensions | 220 x 160 x 83.3 ~ mm (WxDxH) (Without Bezel) |
| Encryption | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Features | MU-MIMO Traffic Analyzer Adaptive QoS WTFast Gamers Private Network AiProtection Pro Parental Control Guest Network : 2.4 GHz x 3, 5 GHz x 3 Mac OS Backup Enhanced media server (AiPlayer app compatible) – Image : Jpeg – Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg – Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov AiCloud personal cloud service 3G/4G data sharing Printer Server – Multifunctional printer support (Windows only) – LPR protocol support Download Master – Support bt, nzb, http, ed2k – Support encryption, DHT, PEX and magnet link – Upload and download bandwidth control – Download scheduling AiDisk file server – Samba and FTP server with account management IPTV support Roaming Assist |
| Firewall & Access Control | Access control：Parental control, Network service filter, URL filter, Port filter |
| LED Indicator | Power x 1 Wi-Fi x 2 WAN x 1 LAN x 4 WPS x 1 |
| Management | UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log |
| Memory | 256 MB Flash 512 MB RAM |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Operation mode | Wireless router mode Access point mode Media bridge mode |
| OS Support | Windows® 10 Windows® 8 Windows® 7 Mac OS X 10.6 Mac OS X 10.7 Mac OS X 10.8 Linux |
| Ports | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4 USB 2.0 x 1 USB 3.0 x 1 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current |
| Processor | 1.8 GHz dual-core processor |
| Product Segment | AC2900 ultimate AC performance : 750+2167 Mbps |
| Product Weight (g) | 872 g |
| Transmit/Receive | MIMO technology 2.4 GHz 3 x 3 5 GHz 4 x 4 |
| VPN | IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client |
| WAN | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Wi-Fi Technology | Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80 MHz bandwidth |
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 |
| Warranty | 2 Years Replacement. |
