Description
| AiMesh | AiMesh Primary AiMesh router AiMesh node |
| AiProtection | AiProtection Classic Malicious site blocking Infected Device Prevention and Blocking |
| Antenna | External antenna x 4 |
| Boosts speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Button | WPS Button, Reset Button, Power Switch |
| Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) : up to 1734 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps |
| LAN | DHCP Server IPTV Manually assign IP address |
| LED Indicator | Power x 1 2.4G x 1 5G x 1 LAN x 1 WAN x 1 |
| Memory | 128 MB Flash 256 MB RAM |
| Operating Frequency | 2.4GHz / 5GHz |
| Parental Control | Parental Control Parental Control Customized Internet schedule |
| Ports | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 1.5 A current |
| Processor | 1.7GHz quad-core processor |
| Product Segment | AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps |
| Product Weight (g) | 374g |
| Router APP | ASUS Router APP |
| Traffic | Bandwidth limiter Traditional QoS Traffic Monitor Real-time traffic monitor Wired Traffic Monitor Wireless Traffic Monitor |
| VPN | VPN Client L2TP VPN Client OVPN VPN Client PPTP VPN Server IPSec VPN Server OVPN VPN Server PPTP |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN Port triggering DMZ DDNS Let’s Encrypt |
| Wireless | IPv6 Wi-Fi Encryption : Open system, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise UTF-8 SSID Guest Network WPS WiFi MAC address filter Wireless scheduler Airtime fairness RADIUS Client Universal beamforming Explicit beamforming |
| Model Name | RT-AX57 |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| AX technology | Yes |
| Alexa | Support Alexa skill |
| Administration | Operating mode : Access Point, AiMesh Node, Media Bridge, Repeater, Router Operating system : ASUSWRT Free OS upgrade Firewall SSH Wake on LAN (WOL) Configuration backup and restore Diagnosis tools Feedback system System log |
| Warranty | 2 Years Brand Warranty. |
