Description
| AiMesh | AiMesh Primary AiMesh router AiMesh node |
| AiProtection | AiProtection Pro AiProtection Malicious site blocking Two-Way IPS Infected Device Prevention and Blocking |
| Antenna | External antenna x 4 |
| Boosts speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Button | WPS Button, Reset Button, Power Switch |
| Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) (1024QAM) : up to 1733 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps |
| LAN | DHCP Server IPTV Manually assign IP address Maximum manually assign IP address rule : 64 |
| LED Indicator | Power x 1 2.4G x 1 5G x 1 LAN x 4 WAN x 1 Power x 1 2.4G x 1 5G x 1 LAN x 4 WAN x 1 |
| Memory | 256 MB Flash 512 MB RAM 256 MB Flash 512 MB RAM |
| Operating Frequency | 2.4G Hz / 5 GHz |
| Parental Control | Parental Control Parental Control Customized Internet schedule |
| Ports | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4 USB 3.2 Gen 1 x 1 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current DC Output : 12 V with max. 2 A current |
| Processor | 1.5 GHz tri-core processor |
| Product Segment | AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps |
| Product Weight (g) | 538 g |
| Router APP | ASUS Router APP |
| Traffic | Adaptive QoS Bandwidth Monitor Bandwidth limiter Maximum Bandwidth limiter rule : 32 Traditional QoS Maximum Traditional QoS rule : 32 Traffic Monitor Real-time traffic monitor Wired Traffic Monitor Wireless Traffic Monitor Traffic Analyzer Traffic analysis period : Daily, Weekly, Monthly Website history |
| Transmit/Receive | 2.4GHz 2×2 5GHz 2×2 |
| USB application | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 3G/4G LTE dongle HDD hibernation Safely Remove disk AiCloud Download master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder privileges |
| VPN | VPN Client L2TP VPN Client OVPN VPN Client PPTP VPN Server IPSec VPN Server OVPN VPN Server PPTP |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN 3G/4G LTE dongle Android tethering Port forwarding Maximum port forwarding rule : 64 Port triggering Maximum port triggering rule : 32 DMZ DDNS NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay |
| Wireless | IPv6 Wi-Fi Encryption : WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise UTF-8 SSID Guest Network Maximum Guest Network rule : 2.4GHz x3, 5GHz x3 Guest Network Connection time limit WPS WiFi MAC address filter Maximum MAC filters : 64 Wireless scheduler Airtime fairness RADIUS Client Universal beamforming Explicit beamforming |
| Model Name | RT-AX58U |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| AX technology | Yes |
| Package content | RT-AX58U WiFi router RJ-45 cable Power adapter Quick Start Guide Warranty card |
| Administration | Operating mode : Wireless router mode Access point mode Media bridge mode Repeater mode AiMesh node mode Operating system : ASUSWRT Free OS upgrade Firewall Maximum Firewall keyword filter : 64 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 SSH Wake on LAN (WOL) Configuration backup and restore Diagnosis tools Feedback system System log |
| Warranty | 2 Years Brand Warranty. |
