Description
| AiMesh | AiMesh Primary AiMesh router AiMesh node |
| AiProtection | AiProtection Pro AiProtection Malicious site blocking Two-Way IPS Infected Device Prevention and Blocking |
| Antenna | External antenna x 3 Internal PCB antenna x 1 |
| Boosts speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Button | WPS Button, Reset Button, Power Switch, LED on/off Button |
| Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 450 Mbps WiFi 4 (802.11n) (1024QAM) : up to 750 Mbps WiFi 5 (802.11ac) (1024QAM) : up to 4333 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 861 Mbps WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps |
| Game | Game Boost / Acceleration |
| LAN | DHCP Server IPTV LAN Link Aggregation Manually assign IP address Maximum manually assign IP address rule : 64 |
| LED Indicator | Power x 1 2.4GHz x 1 5GHz x 1 WAN x 1 LAN x 4 WPS x 1 USB x 1 |
| Memory | RT-AX86S: 256MB Flash 512MB RAM |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Parental Control | Parental Control Parental Control Customized Internet schedule |
| Ports | RT-AX86S: RJ45 for 10/100/1000 BaseT for WAN x 1 RJ45 for 10/100/1000 BaseT for LAN x 4 Five (5) 10/100/1000 Mbps Gigabit Ethernet ports — LAN: 4xGbE (2x port aggregation LAN) — WAN: 1 GbE — Multi-Gig: Ability to aggregate two Gigabit LAN ports and two Gigabit WAN ports (configurable) concurrently. USB 3.2 Gen1 x1, 2.0 x1 |
| Power Supply | RT-AX86S : 12 V with max.3 A current / 19.5 V with max. 2.31 A current |
| Processor | RT-AX86S:1.8GHz dual- core processor |
| Product Segment | AX5700 ultimate AX performance : 861+4804 Mbps |
| Product Weight (g) | 814.5 g |
| Router APP | ASUS Router APP |
| Traffic | Adaptive QoS Bandwidth Monitor Bandwidth limiter Maximum Bandwidth limiter rule : 32 Traditional QoS Maximum Traditional QoS rule : 32 Traffic Monitor Real-time traffic monitor Wired Traffic Monitor Wireless Traffic Monitor Traffic Analyzer Traffic analysis period : Daily, Weekly, Monthly Website history |
| Transmit/Receive | 2.4GHz 3×3 5GHz 4×4 |
| USB application | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 3G/4G LTE dongle HDD hibernation Safely Remove disk AiCloud Download master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder privileges |
| VPN | VPN Client L2TP VPN Client OVPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server OVPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN WAN Aggregation 3G/4G LTE dongle Android tethering Port forwarding Maximum port forwarding rule : 64 Port triggering Maximum port triggering rule : 32 DMZ DDNS NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, PPPoE relay Safe browsing DNS-over-TLS |
| Wireless | IPv6 Wi-Fi Encryption : WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support UTF-8 SSID Guest Network Maximum Guest Network rule : 2.4GHz x3, 5GHz x3 Guest Network Connection time limit WPS WiFi MAC address filter Maximum MAC filters : 64 Wireless scheduler Airtime fairness RADIUS Client Universal beamforming Explicit beamforming |
| Model Name | RT-AX86S |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| AX technology | Yes |
| Package content | RT-AX86S WiFi router RJ-45 cable Power adapter Quick Start Guide Warranty card |
| Alexa | Support Alexa skill |
| Administration | Operating mode : Wireless router mode,Access point mode,Media bridge mode,Repeater mode,AiMesh node mode Operating system : ASUSWRT Free OS upgrade Firewall Maximum Firewall keyword filter : 64 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 SSH Wake on LAN (WOL) Configuration backup and restore Diagnosis tools Feedback system System log New Device Connect Notification Login Captcha Connection Diagnosis Security Scan Auto Firmware Update |
| Warranty | 2 Years Brand Warranty. |
