Description
| Antenna | External antenna x 4 |
| Button | WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button |
| Coverage | Very large homes |
| Data Rate | 802.11a : 6,9,12,18,24,36,48,54 Mbps 802.11b : 1, 2, 5.5, 11 Mbps 802.11g : 6,9,12,18,24,36,48,54 Mbps 802.11n : up to 600 Mbps 802.11n (1024 QAM) : up to 1000 Mbps 802.11ac (1024 QAM) : up to 4333 Mbps 802.11ac : up to 3466 Mbps 802.11ax (2.4GHz) : up to 1148 Mbps 802.11ax (5GHz) : up to 4804 Mbps |
| Dimensions | 11.8 x 7.4 x 2.4 ~ ” (WxDxH) (Without Bezel) |
| Encryption | WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Features | Link Aggregation – 802.3ad MU-MIMO Traffic Analyzer Adaptive QoS WTFast Gamers Private Network AiProtection Pro Parental Control Guest Network : 2.4 GHz x 3, 5 GHz x 3 VPN server : PPTP Server, OpenVPN Server, IPSec server VPN client : PPTP client, L2TP client, OpenVPN client NAT Pass-Through :PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay Mac OS Backup Enhanced media server (AiPlayer app compatible) – Image : Jpeg – Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg – Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov AiCloud personal cloud service 3G/4G data sharing Printer Server – Multifunctional printer support (Windows only) – LPR protocol support Download Master – Support bt, nzb, http, ed2k – Support encryption, DHT, PEX and magnet link – Upload and download bandwidth control – Download scheduling AiDisk file server – Samba and FTP server with account management Dual WAN IPTV support Roaming Assist |
| Firewall & Access Control | Firewall: SPI intrusion detection, DoS protection Access control：Parental control, Network service filter, URL filter, Port filter |
| LED Indicator | Power x 1 Wi-Fi x 2 WAN x 1 LAN x 1 USB x 2 WPS x 1 |
| Management | UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log |
| Memory | 256 MB Flash 1 GB RAM |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Operation mode | Wireless router mode Access point mode Media bridge mode |
| OS Support | Windows® 10 Windows® 8 Windows® 7 Mac OS X 10.6 Mac OS X 10.7 Mac OS X 10.8 |
| Ports | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 8 USB 3.1 Gen 1 x 2 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 2.37 A current |
| Processor | 1.8 GHz quad-core processor |
| Product Segment | AX6000 ultimate AX performance |
| Product Weight (g) | 1010 g |
| Transmit/Receive | External antenna x 4 |
| VPN | IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client |
| WAN | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Wi-Fi Technology | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6 |
| Warranty | 2 Years Replacement. |
