Description
| Audio Interface | 5.1 PCI Express |
| Audio Performance | Output Signal-to-Noise Ratio (A-Weighted) (Front-out) : 116 dB Input Signal-to-Noise Ratio (A-Weighted) : 110 dB Output THD+N at 1kHz (Front-out) : 0.00251 %(-92 dB) Input THD+N at 1kHz : 0.00251 %(-92 dB) Frequency Response (-3dB, 24bit/192KHz input) : 10 Hz to 87 KHz Headphone output : 2 Vrms (5.65 Vp-p) |
| Chipset | C-Media USB2.0 6620A High-Definition Sound Processor (Max. 192KHz/24bit) |
| Digital-to-analog Converter(DAC) | Realtek S1220A (120dB SNR, Max. 192KHz/24bit) |
| Sample Rate and Resolution | Analog Playback Sample Rate and Resolution : 44.1K/48K/96K/192KHz @ 16bit/24bit Analog Recording Sample Rate and Resolution : 44.1K/48K/96K/192KHz @ 16bit/24bit S/PDIF Digital Output : 44.1K/48K/96K/192KHz @ 16bit/24bit ASIO 2.2 Driver Support : 44.1K/48K/96K/192KHz @ 16bit/24bit |
| Connectivity | Analog Output: 3 x 3.5 mm jack (1/8″) (Front out/Side out/Rear out) Analog Input: 1 x 3.5 mm jack (1/8″) (Line-in/Mic-in) Digital: 1 x S/PDIF out (1 x Optical (Toslink)) 1 x Front-Panel Header |
| Special Features | Smart Volume Normalizer™ Xear 3D™ Virtual Speaker Shifter Xear Surround™ Magic Voice™ |
| Accessories | Low-profile bracket x 1 Driver CD x 1 Quick start guide x 1 |
| Warranty | 1-year brand warranty |
