Description
| Technology | Contact Image Sensor (CIS) |
| Light Source | LED |
| Document feeding mode | ADF, Flatbed |
| Optical Resolution (dpi) | 600 |
| Output Resolution (dpi) | 1200 |
| File Formats | BMP, PNG, GIF, JPEG, Single-Page PDF, Multi-Page PDF, Multi-TIFF, TIFF, RTF, TXT, OCR( for iScan only ), XPS, DOC, XLS, PPT, DOCS, XLSX, PPTX, HTML |
| Halftone Patterns | Dither and Error Diffusion |
| Grayscale mode | 16-bit input 8-bit output |
| Color mode | 48-bit input 24-bit output |
| Memory Size | 512MB SDRAM |
| Dimensions (WxDxH) | Maximum：754 x 321 x 301.4 mm (29.7 x 12.6 x 11.9 in), Minimum：545 x 321 x 231.3 mm ( 21.4 x 12.6 x 9.1 in) |
| Weight | 6.9 kg |
| Interface | USB3.2 Gen1x1 |
| Power Consumption | Operation <37.22 W；Ready <8.11 W；Sleep <2.17 W；Off <0.1 W |
| Acoustical Noise | Operation <52 dB；Ready <25 dB |
| Network connection | RJ-45 Ethernet 10/100/1000 Mb, Wi-Fi |
| Recommended Daily Volume | Up to 10,000 sheets |
| Wi-Fi standard | IEEE 802.1b/g/n |
| OS Support | Win 7, Win 8, Win 10, Win11 |
| Bundled Software | TWAIN Driver, ISIS Driver, Button Manager, PaperPort, AVScan, WIA Driver, WorldCard Team |
| Features | Ultrasonic paper jam detection: Yes Long Paper Mode: Up to 200 dpi Color Duplex 240 in. ( 6096 mm )；Up to 300 dpi Color Duplex 218 in. ( 5540 mm )；Up to 600 dpi Color Duplex 59 in. ( 1500 mm ) Card Scan: Embossed card ( Thickness 1.25 mm ) |
| Scan Size | ADF Minimum: 50 x 50 mm ADF Maximum: 216 x 356 mm ( Legal )( 8.5 x 14 in. ) Flatbed Maximum: 216 x 356 mm (Legal) ( 8.5 x 14 in ) ADF Capacity : 100 sheets ( A4 : 80 g/m² or 20 lb. ) Paper Weight (Thickness ): 27g ~ 413 g/m² ( 7 to 110 lb ) ID card thickness: Embossed card ( Thickness 1.25 mm ) |
| Scanning Speed | B/W @ 200dpi, A4: Simplex : 60 ppm；Duplex :120 ipm, Flatbed : 1.5 sec B/W @ 300dpi, A4: Simplex : 60 ppm；Duplex : 120 ipm, Flatbed : 1.5 sec Color @ 200dpi, A4: Simplex : 60 ppm；Duplex : 120 ipm, Flatbed : 1.5 sec Color @ 300dpi, A4: Flatbed : 1.5 sec, Simplex : 45 ppm；Duplex : 90 ipm |
