Description
| Model | MasterBox 540 |
| Model Number | MB540-KGNN-S00 |
| Type | Mid Tower |
| Color | Black |
| Materials | Steel, Mesh, Plastic, Tempered Glass |
| Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
| Expansion Slots | 7 |
| Drive Bays | 5.25″ Drive Bays: 0 2.5″ / 3.5″ Drive Bays (Combo): 2 2.5″ Drive Bays: 4 |
| I/O Panel | 2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button |
| Pre-installed Fans | 1x 120mm 650~1800RPM SickleFlow PWM ARGB (Rear) |
| Fan Support – Front | 3x 120mm, 2x 140mm |
| Fan Support – Top | 3x 120mm, 2x 140mm |
| Fan Support – Rear | 1x 120mm |
| Radiator Support – Front | 120mm, 140mm, 240mm, 280mm, 360mm |
| Radiator Support – Top | 120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm) |
| Radiator Support – Rear | 120mm |
| Clearance – CPU Cooler | 165mm/6.49″ |
| Clearance – PSU | 180mm/7.08″, 295mm/11.61″ (w/ HDD cage removed) |
| Clearance – GFX | 410mm/16.1″ |
| Dust Filters | Top, Front, Bottom |
| Power Supply Support | ATX |
| Dimensions (L x W x H) | 499.3 x 208.6 x 498mm (incl. Protrusions), 488.3 x 208.6 x 498mm (excl. Protrusions) |
