Description
| Model | MasterBox TD500 |
| Model Number | MCB-D500D-KANN-S01 |
| Type | Mid Tower |
| Color | Black |
| Materials | Steel, Plastic, Acrylic, Crystalline Tempered Glass |
| Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX*, (*support for up to 12″ x 10.7″, will limit cable management features) |
| Expansion Slots | 7 |
| Drive Bays | 5.25″ Drive Bays: N/A 2.5″ / 3.5″ Drive Bays (Combo): 2 2.5″ Drive Bays: 4 (2+2 combo) |
| I/O Panel | 2 x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB/PWM Hub (may depend on region and model) |
| Pre-installed Fans | 3x 120mm 650~1800RPM SickleFlow PWM ARGB (Front) |
| Fan Support – Front | 3x 120mm, 2x 140mm |
| Fan Support – Top | 3x 120mm, 2x 140mm |
| Fan Support – Rear | 1x 120mm |
| Radiator Support – Front | 120mm, 140mm, 240mm, 280mm, 360mm |
| Radiator Support – Top | 120mm, 240mm, 360mm, (44mm max motherboard component height) |
| Radiator Support – Rear | 120mm |
| Clearance – CPU Cooler | 165mm/6.49″ |
| Clearance – PSU | 180mm/7.08″ |
| Clearance – GFX | 410mm/16.1″ |
| Dust Filters | Top, Front, Bottom |
| Power Supply Support | Bottom Mount, ATX |
| Dimensions (L x W x H) | 493 x 217 x 468 mm |
