Description
| Model | MasterFrame 700 |
| Model Number | MCF-MF700-KGNN-S00 |
| Type | Full Tower |
| Color | Black |
| Materials | Steel, Tempered Glass |
| Motherboard Support | SSI EEB, SSI CEB, XL-ATX, E-ATX, ATX, Micro ATX, Mini ITX |
| Expansion Slots | 8 |
| Drive Bays | 5.25″ Drive Bays: N/A 2.5″ / 3.5″ Drive Bays (Combo): Up to 4 (PSU cover) 2.5″ Drive Bays: 7 (3 SSD brackets + 4 PSU cover) |
| I/O Panel | 2x USB 3.1 Gen 2 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic) |
| Pre-installed Fans | N/A |
| Fan Support – Front | N/A |
| Fan Support – Right side | 3x 120mm / 2x 140mm |
| Fan Support – Top | N/A |
| Fan Support – Left side | 3x 120mm / 2x 140mm |
| Radiator Support – Left side | Up to 280/360mm |
| Radiator Support – Right side | Up to 280/360mm |
| Radiator Support – Top | Up to 360/420mm |
| Clearance – CPU Cooler | 158mm / 6.22inch |
| Clearance – PSU | 210mm / 8.26inch |
| Clearance – GFX | Up to 450mm / 17.71inch, 310mm / 12.20inch recommended for maximum compatibility |
| Cable Routing – Behind Motherboard Tray | 100mm |
| Dust Filters | N/A |
| Power Supply Support | 2x ATX |
| Dimensions (L x W x H) | 702 x 306 x 410mm / 27.64 x 12.05 x 16.14inch (Incl. Panels) |
