Description
| Network Medium | 10BASE-T: Cat 6 UTP(≤250 meter) 100BASE-TX: Cat5 or more UTP (≤100 meter) 1000BASE-TX: Cat5 or more UTP (≤100 meter) |
| Optical | MultiMode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km |
| Working Environment | Operating Temperature: -20℃ ~ 50℃; Storage Temperature: -40℃ ~ 85℃; Operating Humidity: Max 90%, non-condensing Storage Humidity: Max 95%, non-condensing Working Height: Max to 10,000 feet (3,000 meters） Storage Height: Max to 10,000 feet (3,000 meters) |
| Model | FS1026PS1 |
| Network Protocol | IEEE802.3 IEEE802.3u IEEE802.3ab IEEE802.3x IEEE802.3z |
| PoE standard | PoE Standard: IEEE802.3af /IEEE802.3at Max each port: 15.4W ( IEEE 802.3af ) Max each port：30W ( IEEE 802.3at ) PoE compatibility: IEEE 802.3af/at adaptive PoE port output: DC48-55V Power Pin : Power over spare pairs 1/2(+) , 3/6 (-) |
| Power supply | Product Input Voltage: AC100-240V 50/60Hz Output: 52V5.76A, Power Budget: 300W |
| Performance | Bandwidth: 10.8Gbps MAC Address: 2K Packet Buffer Memory: 1M Packet Forwarding Rate: 8Mpps Forwarding Mode: Store-And-Forward |
| MTBF | 100,000 hours |
| Product dimensions | Product Dimension (L*W*H): 320mm*210mm*46mm Package Dimension (L*W*H): 375mm*270mm*85mm N.W: 1.9KG G.W: 2.4KG |
| Connector type | 24-Port 10/100M PoE+ Switch with 2 Gigabit Uplink Ports and 1 SFP Slot |
