Description
| Antenna | Primary: Internal Diversity: Internal, UMTS Optional |
| Battery | Type: Li-ion Polymer Battery Capacity: 2000mAh Endurance: 5-6 hours (normal network situation) |
| Color | Black |
| Data Rate | 802.11b: Up to 11 Mbps 802.11g: Up to 54 Mbps 802.11n: Up to 150 Mbps |
| Dimensions | 97 x 61 x 15.5mm |
| Features | Connection Status Statistics Samba (optional) Device Management Power Mangement Automatic APN matching according to USIM Auto Data Connection USSD Service PIN/PUK Management Network Mode Selection(2G/3G/LTE/Auto) USB RNDIS Device Up to 10 Wi-Fi users/devices DHCP Server IPv4/v6 VPN Passthrough Firewall WPS Security via WEP, WPA-PSK, WPA2-PSK Wi-Fi Settings |
| Firewall & Access Control | Yes |
| Interface | USB: USB2.0 USIM: Single, 4FF |
| LAN | Chipset: RealTek 8192ES Frequency: 2.4GHz Protocol: 802.11b/g/n Channel: 1~13 Antenna: Internal |
| LED Indicator | Power/Battery Status Indicator 4G/3G/2G Network Status Indicator Wi-Fi Status Indicator New SMS Indicator |
| Management | Device Management PIN/PUK Management |
| Operating Frequency | 2.4GHz |
| Operation mode | Network Mode Selection(2G/3G/LTE/Auto) |
| OS Support | Windows: XP/7/8/10 MAC OS: 10.7+ Linux: Ubuntu 13.04+ |
| Power Supply | USB, 5V1A |
| Processor | Qualcomm MDM9x07 / MDM9x25 |
| Product Weight (g) | 92g |
| RF Frequency | LTE FDD: Power Class 3 (23 +/-2dBm) UMTS: Power Class 3 (24 +1.7/-3.7dBm) EDGE: Power Class E2 (GSM850/900: 27dBm; DCS/PCS: 26dBm) |
| Type | MiFi / Pocket Router |
| USB application | USB 2.0 |
| WAN | Frequency Bands LTE: B1/B3/B7/B8/B20/B38/B40/B41 UMTS: B1/B3/B8 Bandwidth Modulation Data Rate |
| Model Name | Cudy MF4 |
| Warranty | 1 Year Brand Warranty |
