Description
| General Information | Power: 12 VDC ± 25%, 0.30 A, max. 3.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: 802.3af, Type 1 Class 3, 36 V to 57 V, 0.20 A to 0.10 A, max. 4.5W Dimension: 68.4 × 65.2 × 161.1 mm (2.7″ × 2.6″ × 6.3″) Package Dimension: 172 × 104 × 80 mm (6.8″ × 4.1″ × 3.1″) Weight: Approx. 420 g (0.9 lb.) With Package Weight Approx. 510g (1.1 lb.) Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Language: English General Function: Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter |
| Camera | Image Sensor: 1/2.8″ Progressive Scan CMOS Max. Resolution: 1920 × 1080 Min. Illumination: Color: 0.001 Lux @ (F1.0, AGC ON) Shutter Time: 1/3 s to 1/100,000 s Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Image | Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Day/Night Switch: Day, Night, Auto, Schedule Wide Dynamic Range (WDR): Digital WDR Image Enhancement: BLC, HLC, 3D DNR |
| Video | Main Stream: 50 Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub-Stream: Video Compression: Video Bit Rate: 32 Kbps to 8 Mbps |
| Lens | Focal Length & FOV: 2.8mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127° 4mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99° Lens Mount: M12 Iris Type: Fixed Aperture: F1.0 Depth Of Field: 2.8 mm: 1.7 m to ∞ 4 mm: 2.1 m to ∞ Lens Type: Fixed focal lens, 2.8 and 4 mm optional |
| Network | Protocols: TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS Simultaneous Live View: Up to 6 channels API: ONVIF (PROFILE S, PROFILE G), ISAPI, SDK User/Host: Up to 32 users. 3 user levels: administrator, operator and user Security: Password protection, complicated password, HTTPS encryption, IP address filter, security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF Client: iVMS-4200, Hik-Connect, Hik-Central Web Browser: Plug-in required live view: IE8, IE9, IE10, IE11 Local service: Chrome 57.0+, Firefox 52.0+ |
| Illuminator | Supplement Light Type: White Light Supplement Light Range: Up to 30 m Smart Supplement Light: Yes |
| Interface | Ethernet Interface: 1 RJ45 10M/100M self-adaptive Ethernet port |
| Event | Basic Event: Motion detection, exception (illegal login) Linkage: Upload to FTP, notify surveillance center, send email, trigger recording, trigger capture *Note: External device is required. |
| Approval | EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Safety: UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Protection: Ingression protection: IP67 (IEC 60529-2013) |
