Description
| General Information | Material: (Front cover: Metal), (Main body: Plastic) Dimension: 223.1 mm × 77.1 mm × 82.6 mm (8.78″ × 3.04″ × 3.25″) Weight : Approx. 350 g (0.77 lb.) Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) Communication: HIKVISION-C Language: English Power Supply: 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. Consumption: Max. 4.2 W |
| Camera | Image Sensor: 2 MP CMOS Max. Resolution: 1920 (H) × 1080 (V) Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light Shutter Time: PAL: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s Day & Night: 24/7 Color Imaging Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360° |
| Image | Image Settings: Brightness;Sharpness;Mirror;AGC Image Parameters Switch:STD/HIGH-SAT Frame Rate: PAL: [email protected] NTSC: [email protected] Wide Dynamic Range: (WDR): ≥130 dB Image Enhancement: BLC;HLC Privacy Mask:4 programmable privacy masks Noise Reduction:3D DN White Balance: Auto/Manual |
| Lens | Lens Type: 3.6 mm, 6 mm fixed focal lens Focal Length & FOV:3.6 mm, horizontal FOV: 83.0°, vertical FOV: 44.4°, diagonal FOV: 98.0° 6 mm, horizontal FOV: 51.0°, vertical FOV: 28.5°, diagonal FOV: 58.7° Lens Mount: M12 |
| Interface | Video Output: Switchable TVI/AHD/CVI/CVBS;1 HD analog output |
| More Information | Approval: Protection IP67 |
| Warranty | 1 Years Brand Warranty |
