Description
General Information | Dimension: 86.7 mm × 81.6 mm × 226 mm(3.4″ × 3.2″ × 8.9″) Weight : 700 g Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or less (non-condensation) Power Supply: 12 VDC±15% Weather Proof: IP66 Consumption: Max. 5W IR Range: Up to 80m |
Camera | Day & Night: IR cut filter with auto switch Angle Adjustment: Pan: 0 – 360°, Tilt: 0 – 180°, Rotation: 0 – 360° Image Sensor: 1MP CMOS Image Sensor Signal System: PAL/NTSC Resolution: 1296(H)x732(V) Min. Illumination: 0.1 Lux @(F1.2,AGC ON), 0 Lux with IR Shutter Time: 1/25(1/30) s to 1/50,000 s |
Image | Video Frame Rate: PAL: [email protected]/[email protected] |
Lens | Lens: 3.6mm (6mm, 8mm, 12mm, 16mm optional), Angle of View: 70.9°(3.6mm), 56.7°(6mm), 38.6°(8mm), 27.5°(12mm), 17.7°(16mm) Lens Mount: M12 |
Interface | Video Output: Switchable TVI/AHD/CVI/CVBS |
More Information | HD Video Output: 1 Analog HD output Synchronization: Internal Synchronization S/N Ratio: More than 62 dB Ingress Protection: IP66 Country Of Origin: China |
Warranty | 1 Years Brand Warranty |
