Description
General Information | Material: Front cover: Mental ,Main Body: Plastic,Bracket: Metal Dimension: 86.7 mm × 81.6 mm × 226 mm (3.4″ × 3.2″ × 8.9″) Weight : 430 g (0.95 lb.) Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) Language: English, Chinese Power Supply: 12 VDC±15% Consumption: Max. 4 W IR Range: Up to 40 m |
Camera | Image Sensor: 2MP CMOS image sensor Max. Resolution: 1920 (H) × 1080 (V) Min. Illumination: 0.01 Lux@(F1.2,AGC ON),0 Lux with IR Shutter Time:1/25 (1/30) s to 1/50,000 s Day & Night: IR cut filter Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° Signal System: PAL/NTSC |
Image | Image Settings: Brightness, Sharpness, DNR, Mirror Frame Rate:PAL: [email protected],NTSC: [email protected] Wide Dynamic Range: (WDR): DWDR Image Enhancement: BLC Day/Night Mode: Smart/color/BW(Black and White) AGC: Low/middle/high |
Lens | Lens Type: 3.6 mm, 2.8 mm, 6 mm, 8 mm, 12 mm fixed lens Focal Length & FOV: 2.8 mm, horizontal FOV: 101°, vertical FOV: 60°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8° 8 mm, horizontal FOV: 39.9°, vertical FOV: 21.9°, diagonal FOV: 46.5° 12 mm, horizontal FOV: 24.6°, vertical FOV: 13.9°, diagonal FOV: 28.1° Lens Mount: M12 |
Interface | Video Output: Switchable TVI/AHD/CVI/CVBS |
More Information | Approval: Protection IP66 |
Warranty | 1 Years Brand Warranty |
