Description
Recording | — |
Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
Encoding Resolution | When 1080p Lite mode not enabled: 4 MP lite/3 MP/1080p/1080p lite/720p/WD1/4CIF/VGA/CIF When 1080p Lite mode enabled: 4 MP lite/3 MP/1080p lite/720p/720p lite/WD1/4CIF/VGA/CIF |
Frame Rate | Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP [email protected]; 1080p lite/720p/WD1/4CIF/VGA/CIF @25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/WD1/4CIF/VGA/[email protected] For 1080p stream access: 1080p/[email protected]; WD1/4CIF/VGA/[email protected] (P)/30fps (N) For 720p stream access: 720p/WD1/4CIF/VGA/[email protected] (P)/30fps (N) When 1080p Lite mode enabled: For 4 MP stream access: 4 MP [email protected]; 1080p lite/720p lite/WD1/4CIF/VGA /[email protected] (P)/30fps (N) For 3 MP stream access: 3 MP/1080p lite/720p lite/WD1/4CIF/VGA/[email protected] For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA/[email protected] (P)/30fps (N) For 720p stream access: 720p/WD1/4CIF/VGA/[email protected] (P)/30fps (N) Sub-stream: WD1/[email protected]; [email protected] (P)/30fps (N) |
Video bit rate | 32 Kbps to 6 Mbps |
Dual stream | Support |
stream type | video, video, and audio |
Audio bit rate | 64 Kbps |
Video and audio | — |
Ip video Input | 16-ch (up to 48-ch) Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
Analog video input | 24-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
HDTVI input | 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 *: The 3 MP signal input is only available for channel 1/2/3/4. |
AHD Input | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
CVBS input | PAL/NTSC |
CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
HDMI1/ VGA output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
HDMI2 output | 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
Audio Input | 16-ch, RCA (2.0 Vp-p, 1 KΩ) |
Audio output | 2-ch, RCA (Linear, 1 KΩ) |
Two way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
synchronous playback | 16-ch |
Network | — |
Remote connections | 128 |
Network protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP |
Network interface | 2, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
Auxiliary Interface | — |
SATA | 8 SATA interfaces |
eSATA | Support |
Capacity | Up to 10 TB capacity for each disk |
serial interfaces | RS-232, RS-485 (full-duplex), Keyboard |
alarm in / out | 16/8 |
usb interface | Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
power supply | 100 to 240 VAC |
consumption | ≤ 45 W |
