Description
| Display | Screen Size: 2.4-inch Type: LCD-TFT display screen |
| Audio | Audio Output: 1 loudspeaker, 1 buzzer |
| Network | Wired Network: TCP/IP, 10/100Mbps, self-adaptive Communication Protocol: TCP/IP, ISUP |
| Interface | Network Interface: 1 Lock Control: 1 Exit Button: 1 Door Contact Input: 1 TAMPER: 1 USB: 1 |
| Authentication | Card Type: EM card Card Reading Distance: 0 to 3.5 cm Fingerprint Module: Optical fingerprint module Fingerprint Comparing Mode: 1:1 and 1:N Fingerprint Recognition Duration: ＜ 1 s |
| Capacity | Card Capacity: 1000 Fingerprint Capacity: 1000 Event Capacity: 100,000 |
| General | Power Supply: 12 VDC/1 A Working Temperature: -10 °C to +55 °C (14 °F to +131 °F) Working Humidity: 10% to 90% (no condensing) Color: Silver Dimensions: 140 mm × 155 mm × 30 mm (5.51″ × 6.01″ × 1.18″) Self Service Reports (SSR): Stand-alone operation, calculate attendance data and export reports via USB interface Installation: Wall mounting |
