Description
| Processor | Intel Core i5-1235U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.4GHz, E-core 0.9 / 3.3GHz, 12MB |
| Graphics | Integrated Intel Iris Xe Graphics Functions as UHD Graphics |
| Chipset | Intel SoC Platform |
| Memory | 8GB Soldered DDR4-3200 |
| Memory Slots | One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable |
| Max Memory | Up to 16GB (8GB soldered + 8GB SO-DIMM) DDR4-3200 offering |
| Storage | 256GB SSD M.2 2242 PCIe 4.0×4 NVMe |
| Storage Support | Models with 45Wh battery: one drive, 1x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB |
| Card Reader | 4-in-1 Card Reader |
| Storage Slot | Models with 45Wh battery: one M.2 slot • One M.2 2280 PCIe 4.0 x4 slot |
| Optical | None |
| Audio Chip | High Definition (HD) Audio |
| Speakers | Stereo speakers, 1.5W x2, Dolby Audio |
| Camera | HD 720p with Privacy Shutter |
| Microphone | 2x, Array |
| Battery | Integrated 45Wh |
| Max Battery Life | Models with 45Wh battery: MobileMark 2018: 6.7 hr Local video (1080p) [email protected]: 10 hr |
| Power Adapter | 65W Round Tip (3-pin) |
| Display | 14″ FHD (1920×1080) TN 250nits Anti-glare |
| Touchscreen | None |
| Keyboard | Non-backlit, English (EU) |
| Case Color | Arctic Grey |
| Surface Treatment | IMR (In-Mold Decoration by Roller) |
| Case Material | PC-ABS (Top), PC-ABS (Bottom) |
| Dimensions (WxDxH) | 324.2 x 215.7 x 19.9 mm (12.76 x 8.49 x 0.78 inches) |
| Weight | Starting at 1.43 kg (3.15 lbs) |
| Operating System | None |
| Bundled Software | None |
| Ethernet | No Onboard Ethernet |
| WLAN + Bluetooth | Wi-Fi 6, 11ax 2×2 + BT5.1 |
| Standard Ports | 1x USB 2.0 1x USB 3.2 Gen 1 1x USB-C 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort 1.2) 1x HDMI 1.4b 1x Card reader 1x Headphone / microphone combo jack (3.5mm) 1x Power connector |
| Security Chip | Firmware TPM 2.0 |
| Fingerprint Reader | None |
| Other Security | Camera privacy shutter |
| Green Certifications | “ENERGY STAR 8.0 ErP Lot 3 RoHS compliant” |
| Base Warranty | 2 Years (Battery + Adapter 1 Year) |
