Description
| Specifications | Product code: RB952Ui-5ac2nD-TC Architecture: MIPSBE CPU: QCA9531 CPU core count: 1 CPU nominal frequency: 650 MHz Switch chip model: QCA9531 Dimensions: 34 x 119 x 98mm RouterOS license: 4 Operating System: RouterOS Size of RAM: 64 MB Storage size: 16 MB Storage type: FLASH MTBF: Approximately 100’000 hours at 25C Tested ambient temperature: -30°C to 70°C |
| Wireless capabilities | Wireless 2.4 GHz Max data rate: 300 Mbit/s Wireless 2.4 GHz number of chains: 2 Wireless 2.4 GHz standards: 802.11b/g/n Antenna gain dBi for 2.4 GHz: 1.5 Wireless 2.4 GHz chip model: QCA9531 Wireless 2.4 GHz generation: Wi-Fi 4 Wireless 5 GHz Max data rate: 433 Mbit/s Wireless 5 GHz number of chains: 1 Wireless 5 GHz standards: 802.11a/n/ac Antenna gain dBi for 5 GHz: 2 Wireless 5 GHz chip model: QCA9887 Wireless 5 GHz generation: Wi-Fi 5 WiFi speed: AC750 |
| Ethernet | 10/100 Ethernet ports : 5 |
| Powering | Number of DC inputs: 2 (DC jack, PoE-IN) DC jack input Voltage: 10-28 V Max power consumption: 20 W Max power consumption without attachments: 8 W Cooling type: Passive PoE in: Passive PoE PoE in input Voltage: 10-28 V |
| PoE-out | PoE-out ports: Ether5 PoE out: Passive PoE Max out per port output (input 18-30 V): 500 mA Max total out (A): 500 mA |
| Certification & Approvals | Certification: CE, FCC, IC, EAC, ROHS IP: IP20 |
| Peripherals | Number of USB ports: 1 USB Power Reset: Yes USB slot type: USB type A Max USB current (A): 1 |
