Description
802.3af/802.3at PoE Injector Port | 8 |
10/100BASE-TX MDI/MDIX Ports | 8 |
10/100/1000BASE-T MDI/MDIX Ports | 2 (Combo) |
1000BASE-X SFP/mini-GBIC Slots | 2 (Combo) |
Switch Architecture | Store-and-Forward |
Switch Fabric | 5.6Gbps/non-blocking |
MAC Address Table | 8K entries |
Switch Throughput | [email protected] bytes |
Maximum Frame Size | 9216 bytes |
LCD Monitor (W x D) | 40.6mm x 30.5mm, 2-inch |
Buttons | Menu, Enter, Back, Up and Down |
Enclosure | Metal |
ESD Protection | Contact discharge of ±4KV DC Air discharge of ±6KV DC |
Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
Surge Protection | ±4KV |
LED | System: Power (Green) 10/100BASE-TX RJ45 Interfaces: 1000BASE-X SFP Interfaces: 1000BASE-T TP Interfaces: |
Dimensions (W x D x H) | 180 x 280 x 44mm (1U height) |
Weight | 1.8kg |
Power Consumption | Max. 130watts/446 BTU |
Fan | 1x Thermal Fan |
Power Requirements | 100~240V AC, 50/60Hz, 2.5A max. |
