Description
| 10/100/1000BASE-T Copper Ports | 9 auto-MDI/MDI-X ports |
| 802.3af/802.3at PoE+ Injector Port | 8 |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 18Gbps |
| MAC Address Table | 2K entries |
| Switch Throughput | 13.3Mpps @64bytes |
| Enclosure | Metal |
| Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
| Jumbo Frame | 9216 bytes |
| DIP Switch | – Default mode for switch architecture – VLAN mode for Port-based VLAN |
| LED | System: Power (Amber) 10/100/1000T RJ45 Interfaces PoE-in-Use (Amber) 10/100/1000 LNK / ACT (Green |
| Dimensions (W x D x H) | 168 x 94 x 32 mm |
| Weight | 419g |
| Power Consumption | Max. 100 watts / 341BTU |
| Power Requirements | 55V DC, 2A |
