Description
10/100/1000BASE-T Copper Ports | 9 auto-MDI/MDI-X ports |
802.3af/802.3at PoE+ Injector Port | 8 |
Switch Architecture | Store-and-Forward |
Switch Fabric | 18Gbps |
MAC Address Table | 2K entries |
Switch Throughput | 13.3Mpps @64bytes |
Enclosure | Metal |
Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
Jumbo Frame | 9216 bytes |
DIP Switch | – Default mode for switch architecture – VLAN mode for Port-based VLAN |
LED | System: Power (Amber) 10/100/1000T RJ45 Interfaces PoE-in-Use (Amber) 10/100/1000 LNK / ACT (Green |
Dimensions (W x D x H) | 168 x 94 x 32 mm |
Weight | 419g |
Power Consumption | Max. 100 watts / 341BTU |
Power Requirements | 55V DC, 2A |
