Description
| Warranty | 01 Year Battery & Service with Spare Parts |
| Input | Voltage Range: 145-280VAC Frequency: 50/60Hz+/-5% |
| Battery | Type: Lead-Acid Maintenance-Free DC Bus: 12V 7.2Ah Number: 1 PCS Recharge time: 6 hours up to 90% capacity Back up time: 05-15 mins (Depending on load) |
| Protection | Spike & Surge Suppression: Yes Over/Under Volt.: Switch to Bat. O / P when main over-regulation range Overload /short Circuit: Fuse & current limited for both Mains and Battery modes |
| Function | Cool start: Cool start computer even there is no main power Automatic recharge: Automatic recharge even UPS is off |
| Output | Voltage (Inverter Mode): 220/230VAC+/-10% Capacity: 390W Frequency (Inverter Mode): 50/60Hz+/-5% Transfer Time: 2~6ms typical Waveform: Modified-Sinewave |
| Basic Information | Model: PG 650 VA – C S Capacity: 650 VA / 390W |
| Indicators | AC Mode: Green lighting Battery Mode: Red lighting Over Load: Yellow lighting |
| Alarm | Beeping Alarm |
| Environmental | Temperature: -5-45° C Humidity: 20% to 90% |
| Management | Intelligent Battery Management |
