Description
| Interface | 5 *100Mbps Auto-identied WAN/LAN Port |
| Power Supply | 9V DC/0.8A |
| Antenna | 2 * 2.4GHz fixed antennas(5dBi), 2 * 5GHz fixed antennas(5dBi), White color |
| LED Indicators | 1*Power, 1*Key for Security Lock, 1*5G, 1*2.4G, 5*WAN/LAN |
| Dimensions (L x W x H) | 174*128*26MM（not including antennas） |
| Standards | IEEE 802.11ac, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| RF Frequency | 2.4GHz/5GHz |
| Data Rate | 2.4GHz: Up to 300Mbps 5GHz: Up to 867Mbps |
| EIRP | 2.4GHz <20dBm 5GHz <20dBm |
| Wireless Security | WPA/WPA2 Mixed |
| Reception Sensitivity | – 2.4G:11b 11M：[email protected]% PER 11g 54M：[email protected]% PER 11n HT20 MCS7：[email protected]% PER HT40 MCS7：[email protected]% PER – 5G: 11a 54M：[email protected]% PER |
| Network | WAN Setting LAN Setting IPTV Setting DHCP&ARP Tables Static Route Routing Table IPv6 Network DDNS |
| Wireless | Basic Settings Advanced Settings Access Control Wireless Schedule Guest Network(Multiple SSID) Band Steering |
| NAT | Virtual Server(Port Forwarding) DMZ VPN passthrough |
| Operation Mode | Router Mode Repeater Mode AP Mode WISP Mode |
| System | Upgrade Firmware Time Zone Settings TR-069 Config Password Settings Reboot Schedule System Log and so on |
| Package Contents | A702R_V4 Wireless Router * 1 Power Adapter * 1 Ethernet Cable * 1 Quick Installation Guide * 1 |
| Environment | Operating Temperature: 0℃~50 ℃ (32 ℉~122℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 5%~95% non-condensing Storage Humidity: 5%~95% non-condensing |
| Warranty | 1 Year. |
| Parental Control | Internet time control based on MAC URL Restrictions |
| QoS | Up/Down speed control on WAN, Bandwidth control based on IP address |
| Firewall | MAC Filtering IP/Port Filtering URL Filtering |
