Description
| Device management | Upgrade Firmware Save/Reload Settings Web Login Password TR-069 config Date and Time Reboot Router Reboot Schedule Reboot Schedule |
| Interface | 4*10/100Mbps LAN Ports 1*10/100Mbps WAN Port 1*USB |
| Output Power | 20dBm (Max.) |
| Status | System Status Statistics System Log |
| Wireless | Basic Settings(including Band, Mode, SSID, Multiple APs, etc.) Security Settings / Site Survey / Schedule Advanced Settings / Access Control / WPS / WDS |
| Power Supply | 9V DC/0.8A |
| Button | RST/WPS Button, 1*Power ON/OFF |
| Antenna | 1*5dBi fixed antenna |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| RF Frequency | 2.4~2.4835GHz |
| Data Rate | 802. 11n: Up to 150Mbps 802.11g: Up to 54Mbps (dynamic) 802.11b: Up to11Mbps (dynamic) |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
| Reception Sensitivity | 135M: -65 [email protected]% PER 54M: -68 [email protected]% PER 11M: -85 [email protected]% PER 6M: -88 [email protected]% PER 1M: -90 [email protected]% PER |
| Firewall | IP Filtering / Port Filtering / MAC Filtering / URL Filtering / Port Forwarding / DMZ / Denial- of- Service / NAT Mapping |
| Environment | Operating Temperature: 0℃~50℃ (32°F~122°F) Storage Temperature: -40~70℃ (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing |
| Warranty | 1 Year Brand Warranty. |
