Description
| Standards | IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Interface | 4*10/100Mbps PoE Ports, 4*10/100Mbps auto-negotiation RJ-45 Ports |
| Dimensions(L x W x H) | – 158.4mm x 106.5mm x 27mm |
| LED | 1*Power, 4*PoE, 1*Overload, 8* Link/Act |
| MAC Address Learning | Auto-Learning, Auto-Aging |
| Port Lightning Protection | 6KV |
| MAC Address Table | 1K |
| Network Media | 10BASE-T: UTP Cat 3 or above cable 100BASE-TX: UTP Cat 5, 5e or above cable |
| Backup Bandwidth | 1.6Gbps |
| Transmission Method | Store-and-forward |
| Package Contents | SW804P Desktop Switch *1 Power Adapter Quick Installation Guide *1 |
| Environment | Operating Temperature: 0℃~50℃ (32℉~122℉) Storage Temperature: -40~70℃ (-40℉~158℉) Operating Humidity: 5%~95% non-condensing Storage Humidity: 5%~95% non-condensing |
| PoE Supply Management | Port 1 to Port 4 support IEEE802.3at/af PoE standard |
| PoE Through Pin | 1 2 4 5 +，3 6 7 8 – |
| Power Input | AC：100-240V～ 50/60Hz DC : 48V /1.25A（Power Adapter ） |
| Power Consumption | In full configuration：<63W PoE Max Power Supply：58W |
