Description
| Antenna | 2 *Internal Dual Band Antennas |
| Button | 1 *Mesh/RST Button 1* Power Button |
| Data Rate | 2.4GHz: Up to 300Mbps 5GHz: Up to 867Mbps |
| Dimensions | 89 x 89 x 68.5mm |
| EIRP | 2.4GHz <20dBm 5GHz <20dBm |
| Interface | 2 *1000Mbps LAN Ports 1 *1000Mbps WAN Port |
| LED Indicator | 1 *System (Red/Green) |
| Network | WAN Setting LAN Setting IP/MAC Binding DDNS Setting IPTV Setting IPv6 |
| Operation mode | Mesh Mode |
| Power Supply | DC 12V/1A |
| Reception Sensitivity | – 2.4G: 11b: <-81dbm；
11g: <-68dbm； 11n: HT20<-65dbm HT40: <-62dbm – 5G: 11a:<-68dbm； 11n: HT20<-65dbm HT40: <-62dbm 11ac: <-51dbm |
| RF Frequency | 2.4GHz/5GHz |
| WAN | Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
| Wireless | Basic setup Parental Control |
| Wireless Security | 64/128-bit WEP, WPA, WPA2 and WPA-Mixed |
| Network Standard | IEEE 802.11ac , IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n , IEEE 802.11s , |
