Description
| Chipsets | MT7621A+MT7915DA+MT7975DN |
| Flash/RAM | 16Mbyte/256Mbyte |
| Interface | 4*1000Mbps LAN Ports 1*1000Mbps WAN Port |
| Power Supply | 12V DC/1A |
| Antenna | 4 * 5dBi fixed external antennas |
| LED Indicators | 1 *SYS(Blue) 4 *LAN(Green), 1 *WAN(Green) |
| Dimensions (L x W x H) | 241.0 x 147.0 x 48.5mm |
| Wireless | IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a |
| Standards | |
| RF Frequency | 2.4~2.4835GHz 5.18~5.825GHz |
| Data Rate | 2.4GHz: Up to 573.5Mbps (2*2 40MHz) 5GHz: Up to 1201Mbps (2*2 80MHz) |
| EIRP | 2.4GHz <20dBm 5GHz <20dBm |
| Wireless Security | WPA2/WPA Mixed WPA3 |
| Reception Sensitivity | 2.4G: 11b: <-85dbm; 11g: <-72dbm; 11n: HT20<-68dbm HT40: <-65dbm 5G: 11a:<-72dbm; 11n: HT20<-68dbm HT40: <-65dbm 11ac: <-55dbm 11ax VHT80 : <-46dbm |
| Software | |
| Basic | Internet Settings Wireless Settings Parental Control Guest Network Settings Smart QoS |
| Network | Internet Setup LAN Setup DDNS IPTV IPv6 |
| Wireless | Wireless Setup Guest Network Schedule Access Control Advanced Parental Control Smart QoS |
| Device Management | Routing Table Static Route IP/MAC Binding |
| Security | IP/Port Filtering MAC Filtering URL Filtering |
| NAT | Virtual Server DMZ VPN Passthrough |
| Remote network | L2TP Server Shadow socks Account Manage |
| Service | Remote UPnP Schedule |
| Tools | Change Password Time Setup System Upgrade Diagnosis Route Tracking Log |
| Operation Mode | Gateway mode Bridge mode Repeater mode WISP mode |
| Other Function | Multi-language automatic adaptation Domain Access QR Code LED Control Reboot Logout |
| Others | |
| Package Contents | X5000R Wireless Router *1 Power Adapter *1 RJ45 Ethernet Cable *1 Quick Installation Guide *1 |
| Environment | Operating Temperature: 0℃~50 ℃ (32 ℉~122℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 5%~95% non-condensing Storage Humidity: 5%~95% non-condensing |
| Warranty | 1 Year Brand Warranty. |
